Flour Transport Semi Trailer
Flour transport semi trailer is a semi-trailer specially used for transporting flour and other powder granular materials. It usually consists of two parts: a tractor and a semi-trailer, the tractor provides power, and the semi-trailer is responsible for loading and transporting goods such as flour. This semi-trailer is designed with special tanks for loading and storing flour, ensuring safety and stability during transportation.
Vertical flour transport semi trailer technical features
◆ Food grade aluminum alloy tank plate effectively ensures the cleanliness of the medium
◆ Light curb weight, the entire vehicle weighs only 6.8 tons
◆ Wide range of material usage and high transportation efficiency.The residual rate is almost zero, and its performance far exceeds that of horizontal tank semi trailers.
◆ Mixed material transportation without layering
The manhole cover adopts a 6-jaw design, which is easy to operate.
Process Characteristics
Adopting European production and manufacturing processes, intelligent manufacturing technology
The welding of the tank body adopts TIG welding technology, with good forming, deep penetration, and high strength
The tank body, frame, and all accessories of the vehicle are made of aluminum alloy material, which is lighter in weight and more aesthetically pleasing
Adopting an air suspension system, with good driving smoothness and better braking performance, extending the service life of tires.
Made with advanced domestic technology, high-quality food grade aluminum alloy material is selected for production. The design is scientific, the layout is reasonable, and it has the characteristics of light weight, large load-bearing capacity, fast unloading, and low residual amount. Its performance far exceeds that of horizontal tank trucks.
Specification
|
Size |
10700mm*2500mm*4000mm |
|
Volume |
30-60m³ |
|
Tank body |
Aluminum alloy/5mm steel sheet (Optional) |
|
End plate |
Aluminum/6mm .ball shape (Optional) |
|
Axle |
3 axle FUWA brand 13T (Optional) |
|
Suspension |
Air suspension (Optional) |
|
Air bag |
6pcs (Optional) |
|
Manhole cover |
500mm manhole cover .2 sets |
|
Tire |
12R22.5 12pcs (Brand and specs optional) |
|
Wheel rim |
9.0-22.5 12pcs (Brand and specs optional) |
|
Discharge valve |
4"disc valve |
|
Discharge pipe |
4"seamless steel tube |
|
Outlet pipe |
4"rubber hose.6m |
|
Kingpin |
2"/3.5" bolt-in /welded king pin |
|
Landing gear |
Two-speed, manual operating ,heavy duty landing gear 28T |
|
Engine |
Diesel engine (Optional) |
|
Air compressor |
37 KW, 0.2Mpa. 1000r/Min (Brand and specs optional) |
|
Compartment |
Single (Optional) |
|
Braking system |
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
|
ABS |
Optional |
|
Light |
LED 8 side lights and 2 rear lights 2 width lamp |
|
Air-charging system |
2"main hole.2"check valve .1.5"safe valve.0.4Mpa.gauge |
|
Quadratic blow |
1" diameter check valve |
|
Painting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
Accessories |
One standard tool box,one spare tire carrier,one crank,one shaft head wrench,four side light,two rear light |
The correct use of flour transport semi-trailer needs to pay attention to the following points:
1. Before loading flour, check whether the inside of the tank is clean and free of debris, and confirm whether the loading port and discharge port are smooth.
2. When loading flour, the loading speed and height should be controlled to avoid damage caused by flour impact on the tank.
3. In the process of driving, the vehicle should be kept stable, avoid sudden braking and sharp turns and other operations to ensure the stability of flour in the tank.
4. When unloading, the unloading speed and flow rate should be controlled to avoid splashing or leaking of flour.
