Petroleum & Chemical
Your Professional Petroleum & Chemical Tanker Trailers Supplier
Shandong tank automobile company limited is a professional semi trailer and trailer parts exporter. Our company have our own semi trailer and trailer parts factory. Our factory covering an area of 200000 square meters, and over 130 employees.
At present, the company mainly specializing in manufacturing special vehicles such as low bed semi trailer, flatbed semi trailer, oil tank semi trailer, bulk cement semi trailer, dumper semi trailer and so on. And our trailer parts factory mainly manufacture semi trailer axle, suspension and landing gear.
Our boasts strong technical force, advanced line production equipment of welding and excellent quality guarantee system, modern testing means and high qualified specialist technicians, making the products trusted and welcomed widely by the users.
Pre sales: We can support professional technical. We have experienced technicians who design the most reasonable trailers for our customers.
In sale: Track trailer production progress and share real-time product status with customers in a timely manner.
After sales: Equipped with various vulnerable parts, track the usage of customer vehicles, and promptly solve problems found.
Specification
|
Size |
10500mm*2500mm*3700mm |
|
Volume |
30-60m³ |
|
Tank body |
Q235A/4-5mm steel sheet (Stainless steel/aluminium alloy optional) |
|
End plate |
Q235A/6mm .ball shape (Stainless steel/aluminium alloy optional) |
|
Axle |
3 axle FUWA brand 13T (Optional) |
|
Suspension |
Mechanical suspension American type (Optional) |
|
Leaf spring |
Leaf spring 10pcs*90*13mm (Optional) |
|
Manhole cover |
500mm manhole cover with breath valve .2 sets (Optional) |
|
Tire |
12R22.5 12pcs (Brand and specs optional) |
|
Wheel rim |
9.0-22.5 12pcs (Brand and specs optional) |
|
Discharge valve |
4"disc valve |
|
Discharge pipe |
4"seamless steel tube |
|
Bottom valve |
1 Set |
|
Kingpin |
2"/3.5" bolt-in /welded king pin |
|
Landing gear |
Two-speed, manual operating ,heavy duty landing gear 28T |
|
Compartment |
Single (Optional) |
|
Braking system |
WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
|
ABS |
Optional |
|
Light |
LED 8 side lights and 2 rear lights 2 width lamp |
|
Painting |
Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
|
Accessories |
One standard tool box,one spare tire carrier,one crank,one shaft head wrench,four side light,two rear light |
Features of Petroleum & Chemical Tanker Trailers
More stability:
Round edges require less reinforcement compared to a typical container with corners and straight sides, reducing the pressure on the tank itself.
Helps prevent liquid surge:
Liquid naturally moves inside the tanker, but the cylindrical shape helps minimize excessive surging. Some tankers are also equipped with bulkheads to further reduce surge. Since tankers have weight limits, they cannot be completely filled, meaning liquid surge is always a consideration for drivers.
Lower center of gravity:
This design is ideal when transporting flammable materials like fuel and oil, as it lowers the risk of tipping and increases safety.
Easier extraction and cleaning:
The rounded sides of a cylindrical tanker facilitate easier extraction, as liquid can naturally flow towards the lowest point. This design also prevents material from getting stuck in hard-to-reach corners, leaving less product residue behind. As a result, there is less contamination for the next load.
Petroleum & Chemical Tanker Trailer Safety and Compliance
Hazardous Materials Endorsement (HME):
Drivers need this CDL endorsement to legally transport hazardous liquids.
Inspection Protocols:
Regular checks ensure tanker trailers meet federal and state safety requirements.
Spill Prevention:
Equip trailers with spill kits, containment systems, and emergency response plans to handle accidents.
Logistics
We will help you to choose the best shipping way according to your detail requirements. By sea, by air, or by express, etc.
The time frame of an order delivery is divided into two parts:
Processing time: 7-14 Days
Shipping time: 20~30 Days
Shipping methods:
DDP, DAP, EXW, etc.
Shipping fee:
The shipping fee will be changed according to every pacel's weight.
