3 Axle Flatbed Semi Trailer

3 axle flatbed semi trailer also mainly used for transporting containers. Max payload can be 60t. We can install 4/8/10pcs container lock according to different requirements. The size is optional for 40/45ft containers. If customers want customize multi-purpose semi trailer we can install columns for transporting wood or install side board and front board for transporting bulk cargoes. Flatbed semi trailer is very popular in Africa.

Send Inquiry

Product Introduction

The axle and suspension we have many brands to choose such as FUWA, BPW, L1 or our local brand. Local brands axle and suspension also have good quality. Customer can use both American type and Germany type axle and suspension.

Our 3 axle flatbed semi trailer from engineer design the drawing to cutting steel, welding main beam and other accessories, sandblasting rust removal, clean up welding slag, painting, install axle and tires, install electrical circuits, each step has strict quality control to make sure the semi trailer have longer service life.

Specification

Size	12300mm2500mm1550mm(Optional)
Payload	40-60t
Main beam	Top flange 14mm,width140mm;Middle Flange 8mm height 500mm;bottom flange16mm,width 140mm(Thickness Optional)
Side beam	16# channel steel (Optional)
Cross member	12# channel steel (Optional)
Floor	3mm checkered plate (Optional)
Side wall	Removable
Front board	Removable
Axle	3 axle or 4 axle(Optional)
Suspension	American type suspension (Optional)
Leaf spring	10pcs13mm90mm (Optional)
Tire	12R22.5 12pcs (Brand and specs optional)
Wheel rim	9.0-22.5 12pcs (Brand and specs optional)
Kingpin	2"/3.5" bolt-in /welded king pin
Landing gear	Two-speed, manual operating ,heavy duty landing gear 28T
Twist lock	8pcs
Braking system	WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
ABS/EBS	Optional
Light	LED 8 side lights and 2 rear lights 2 width lamp
Painting	Complete chassis sand blasting to clean rust ,1coat of anti corrosive prime,2coats of final painting
Accessories	One tool box,one or two spare tire carriers,one crank,one shaft head wrench,four side lights,two rear lights

FAQ

Q: What is the performance of the three-axle flat semi-trailer?

A: The three-axis flat semi-trailer usually has high stability and safety, and can meet the transportation needs of heavy cargo. At the same time, the noise and vibration during the driving process are also relatively low, which improves the driver's driving comfort and the transport quality of goods.

Q: What is the structure of the three-axis flat semi-trailer?

A: The three-axle flat semi-trailer usually adopts a concave beam frame, the front section of the frame is gooseneck (connected with the tractor), the middle section is the cargo platform (the lowest part of the frame), and the rear end is the wheel frame (including wheels). The low plane of the cargo platform ensures the smoothness of transportation.

Q: What is the 3 axle flatbed semi trailer?

A: The 3 axle flatbed semi trailer is a three-axle, flat-plate loading part of the semi-trailer. It is usually used for medium and long distance cargo transport, especially for transporting heavy duty goods such as heavy vehicles, construction machinery, and large equipment.
